Main Bearing for Cummins ISX15 QSX15 SHACMAN FOTON Dongfeng Truck Heavy Duty and Long-lasting

Purpose : for replace/repair

Year : 1997-2007, 2003-2013, 1983-2007

Model : ISM, 6C Series, 8.3L

Engine : -, -, -

OE NO. : 5406110 3800298 3678556 3678555 3680202

Car Fitment : Cummins

Warranty : 3 months

Place of Origin : Shandong, China

Brand Name : car

Car Model : cummins

Condition : New, Brand-new

Model Number : 5406110 3800298 3678556 3678555 3680202

Product name : 5406110 3800298 3678556 3678555 3680202 Main bearing

Application : cummins

Material : Steel/aluminum/titanium

Size : Standard Size

MOQ : 5 set

Packing : Color Packing

Delivery time : 3-7days

Quality : 100% Tested

Payment terms : T/T

Price : CN¥508.36/acres 1-49 acres

Contact Now

5406110 3800298 3678556 3678555 3680202 Main Bearing for cummins ISX15 QSX15 dongfeng truck main bearing

Product Description

Main Bearing for Cummins ISX15 QSX15 SHACMAN FOTON Dongfeng Truck Heavy Duty and Long-lasting

5406110 3800298 3678556 3678555 3680202 Main Bearing for cummins ISX15 QSX15 dongfeng truck main bearing

The connecting rod bush includes the connecting rod upper bush and the connecting rod lower bush, which are installed at the connecting part of the connecting rod and the crankshaft to play the roles of wear resistance, connection, support and transmission. When connecting rod bush is assembled, the marks on the top and bottom should not be right or wrong, the direction of the Bush mouth should not be opposite, and the screw should reach the corresponding torque. The connecting rod bush includes the connecting rod upper bush and the connecting rod lower bush, which are installed at the connecting part of the connecting rod and the crankshaft to play the roles of wear resistance, connection, support and transmission. An oil groove is arranged on the inner cylindrical surface of the upper bush of the connecting rod along the circumferential direction, and the corresponding center angle of the oil groove is 80-120 °， The connecting rod bush wall of the oil groove part is provided with an oil through hole. By setting an oil groove with reasonable arc length on the connecting rod bush, the oil can supply oil to the piston at the most appropriate time and time in the engine working process, so as to ensure good piston cooling and avoid cylinder wear and damage; At the same time, the reasonable arc length of the oil groove can ensure the best oil supply, which can not only ensure the reliable cooling, but also avoid the waste of oil and the negative impact of too much oil on the engine. The positioning protrusion on the connecting rod bush enables the connecting rod bush to be assembled in a reasonable position, so that the oil groove of the connecting rod bush can avoid the heavy load bearing area, and ensure the small wear of the connecting rod bush during operation.

5406110 3800298 3678556 3678555 3680202 Main Bearing for cummins ISX15 QSX15 dongfeng truck main bearing

Specification

item	value
OE NO.	5406110 3800298 3678556 3678555 3680202
Warranty	3 months
Place of Origin	China
Certification	2000 ISO/TS16949
Car Model	cummins
Product name	5406110 3800298 3678556 3678555 3680202 Main bearing
Application	cummins
Material	4340 Forged Steel/aluminum/titanium
Size	Standard Size
MOQ	20pieces
Packing	Color Packing
Delivery time	3-7days
Condition	Brand-new
Quality	100% Tested
Payment terms	T/T

5406110 3800298 3678556 3678555 3680202 Main Bearing for cummins ISX15 QSX15 dongfeng truck main bearing

Details Images

The experience of checking the length of the bearing bush is as follows: install the bearing bush, install the bearing bush cover, tighten the bolt at one end according to the specified torque value, insert a 0.05mm thick gasket between the cover at the other end and the plane of the bearing bush seat, when the torque of tightening the bolt at the end reaches 10-20n · m, if the gasket can not be pulled out, it means that the bearing length is too long, and the end without locating tenon should be filed down; If the gasket can be pulled out, it means that the length of bearing bush is suitable; If the gasket cannot be pulled out without tightening to the specified torque value, it indicates that the bearing bush is too short and should be re matched. After the new bearing bush is put into the bearing bush seat, the curvature radius of the bearing bush is required to be greater than that of the seat hole. When the bearing bush is installed into the seat hole, it can closely fit with the bearing seat hole by the elastic force of the bearing bush itself to facilitate heat dissipation. Check whether the bearing bush has a mute sound. Tap the back of the bearing bush to listen. If there is a mute sound, it indicates that the alloy is not firmly combined with the base plate, so it should be re matched. When selecting bearing bush, the fit clearance must be checked. During inspection, measure the bearing bush and journal with cylinder gauge and micrometer, and the difference is the fit clearance. The inspection method for the fit clearance of bearing bush is as follows: for the connecting rod bush, apply a thin layer of oil on the bearing bush, put the connecting rod on the corresponding journal, tighten the bolts according to the specified torque value, and then swing the connecting rod by hand, which can rotate 1 ~ 1 / 2 circle, pull the connecting rod along the axis direction, and it meets the requirements if there is no clearance feeling; For the curved bearing bush, apply oil on the surface of each journal and bearing bush, install the crankshaft, tighten the bolts according to the specified torque value, and pull the crankshaft with both hands. It is appropriate that the crankshaft can rotate 1 / 2 turn, and the rotation is light, uniform and without blocking.

Packing & Delivery

details1. Our packing uses export wooden cases, plastic boxes, cartons or pallets. All the package are very strong, the wooden box is firmly bound, the package is covered with a waterproof film to prevent water or damage during transportation.Before packing, we can also stick corresponding labels and shipping marks according to your needs. All our goods are well packed.
2. According to the quantity, we can use express delivery, air transportation or ocean transportation, automobile transportation, railway transportation, etc. we have our own freight forwarders, and we can also use the designated freight forwarders of customers, which can meet various delivery requirements of customers, such as EXW, FOB, CIF, etc.It can also be exported from many
ports in China. Such as Qingdao port, Ningbo port, Lianyungang port, Tianjin port, Suifenhe River and Alashankou in China.
3. We can also send the goods by express if the customers have less goods. According to customer's request, we can use express .such as DHL, TNT, EMS, FedEx, etc. the delivery time is 3-7. Safe, fast and convenient. It's also a good choice for you.

5406110 3800298 3678556 3678555 3680202 Main Bearing for cummins ISX15 QSX15 dongfeng truck main bearing

Company Profile

Jinan Carman International Trade Co., Ltd. is located in Jinan city with beautiful scenery and convenient transportation. It is a joint-stock enterprise specializing in the R & D, manufacturing, sales and service of internal combustion engine sliding bearings and related products. In 2013, 18429 square meters of land was acquired in Jinan Industrial Development Zone and a new plant was built. The total construction area of the project was 4727 square meters, with a total investment of 40 million yuan. The company has a perfect modern management system and product R & D system, has a high-level professional technical force and a stable professional team, and can independently develop, develop and produce sheet tiles, flanging tiles and all kinds of roll bushings. Its products cover the medium and heavy truck market, and has developed heavy truck, Weichai, Hangfa, Dachai, Xichai, Dongfeng Cummins, Chongqing Cummins A variety of products corresponding to domestic and foreign host manufacturers such as DEUTZ, Shangchai and Perkins are exported to overseas after-sales markets such as the United States, Europe, America, Africa, Southeast Asia and the Middle East; The products supporting foreign main engine factories such as Italy I and Iran have successfully passed the bench test and have entered mass production. The company's high-quality products and fine services have won praise from domestic and foreign markets. The company is willing to adhere to the business purpose of "focusing on quality inside, focusing on the market outside, and providing customers with first-class products and services", and work with our customers to develop towards a higher goal!

5406110 3800298 3678556 3678555 3680202 Main Bearing for cummins ISX15 QSX15 dongfeng truck main bearing

Certifications

auto parts are an important factor to support the healthy development of the automobile industry, especially heavy trucks need to have higher requirements for different environments and different roads. The wear resistance, durability and tenacity of parts will have a direct impact on the safety of the vehicle itself and the driver. Jinan Kaman International Trade Co., Ltd. has been
committed to building excellent suppliers in the automobile industry for many years, providing high-quality vehicle and auto parts services for new and old customers.

FAQ

1. who are we?
We are based in Shandong, China, start from 2013,sell to Eastern Asia(75.00%),Northern Europe(11.00%),Africa(4.00%),Southern Europe(3.00%),South Asia(2.00%),Southeast Asia(2.00%),Western Europe(2.00%),North America(1.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Auto parts,Truck parts,Engine parts,Parts for Cummins,Parts for XCMG

4. why should you buy from us not from other suppliers?
Jinan Carman International Trade Co., Ltd. is located in Jinan city, the capital of Shandong Province. Main products are heavy truck accessories, light truck parts, engineering machinery parts and so on. We have perfect service system.

5. what services can we provide?
Accepted Delivery Terms: 3-5 DAYS
Accepted Payment Currency:T/T
Accepted Payment Type: T/T
Language Spoken:ENGLISH

5406110 3800298 3678556 3678555 3680202 Main Bearing for cummins ISX15 QSX15 dongfeng truck main bearing
